性能特点：
1. 节约耗能，省电环保
2. 智能一体化，前后同步控制，灵活性强
3. 无需更换片材，片材即出即成型产品，具有注塑相似功能，节省人工费用
4. 节约摆放空间
5. 机器产量高，24小时无间断生产，产品质量更稳定，适合大批量且对制品要求高的订单
Function Characteristics
1. Save energy, electricity and environmental protection
2. Intelligent integration, front and rear synchronous control, flexibility control
3. There is no need to replace the sheet, and as the sheet go into the machine,then forming immediately. It has the similar function of injection machine and saves labor costs
4. Save putting space of workshhop
5. The machine has high output, 24-hour continuous production, more stable product quality, and is suitable for orders with high requirements for products in large quantities
Model No./Parameter | 型号/参数 | YPC-105/750 | YPC-80/105/65*750 |
Style | 款式 | 连线机/connection line | 连线机/connection line |
Available Material | 适应物料 | PP PS HIPS PET | PP PS HIPS PET |
Available Product Type | 适应产品类型 | 单色/单层 Single color/Single layer | 多色/多层 Multicolor /Multilayer |
Forming Area(mm) | 成型面积（mm） | 750*450 | 750*450 |
Forming Depth(mm) | 成型深度（mm） | 200 | 200 |
Forming Speed(cycle/min) | 成型速度（转/分） | 25 | 25 |
Max Width(mm) | 最大片材宽度（mm） | 750 | 750 |
Thickness(mm) | 片材厚度（mm） | 0.3-2 | 0.3-2 |
Power of Whole Machine (kw) | 整机功率（kw） | 270 KW | 350 KW |
Machine Dimension(mm) | 机器规格（mm） | 14000*2000*2800 | 14000*2000*2800 |
Machine Weight(kg) | 机器重量（kg) | 15T | 20T |
Machine component | 整机组成部分 | 挤出机+成型机 Extrusion machine+Thermoforming machine | 挤出机+成型机 Extrusion machine+Thermoforming machine |
