环保材料系列- 生物降解（玉米淀粉，PLA,PBS ,PBAT各种生物原料）片材挤出机
Biodegradable Series-Biodegradable material (Corn starch,PLA,PBS ,PBAT) all kinds of biodegradable material)sheet extrusion machine
平行双螺杆排气型生物原料可降解片材机，免结晶干燥机，低耗能，高产量。内部螺杆调节块可自由调整，转换不同生产物料生产功能。调整方便，简单，不易损坏。适用于各种生物原料，如玉米淀粉,PLA,PBS,PBAT等物料，也可以加入辅助的化学原料，机器内部螺杆结构使用生物原料达到完美的改性功能，配合小型抽真空装置共同使用。所生产的片材广泛运用于热成型、吸塑产品领域！
Parallel twin-screw exhaust biodegradable sheet machine for biological raw materials, crystallization free dryer, low energy consumption and high output. The internal screw adjusting block can be adjusted freely to convert the production functions of different production materials. The adjustment is convenient, simple and not easy to damage. It is applicable to various biological raw materials, such as corn starch, PLA, PBS, PBAT and other materials. Auxiliary chemical raw materials can also be added. The internal screw structure of the machine uses biological raw materials to achieve perfect modification function, which can be used together with small vacuum pumping devices. The produced sheets are widely used in the field of thermoforming and Blister products!
性能技术参数 Performance technical parameters
型号 Model | DEPL-900(Ø75) | DEPL-1200(Ø95) |
适应物料 Available Material | Biodegradable material,Corn Starch,PLA,PBS,PBAT |
螺杆直径(MM) Diameter of Screw | 75 | 95 |
主电机功率（KW） Main Motor Power | 110 | 160 |
最大挤出量（KG/H） Max Capacity | 300 | 500 |
片材厚度（MM） Thickness of Sheet | 0.25-2 |
片材宽度（MM） Width of Sheet | 750 | 1000 |
三辊排列方式 Arrangement of Roller | 斜式 Oblique type | 斜式 Oblique type |
总功率（KW） Total Power | 235 | 280 |
整机的外形尺寸（M） Outlook Size | 14*3*2.6 | 14*3*2.6 |
总重量(T) Total Weight | 14 | 15 |
